KEY FEATURES
- Patented side-to-side (STS) boom configuration for unmatched visibility and manoeuvrability in tight spaces.
- Minimal tail swing allows for full rotation without hitting obstacles.
- Powerful turbocharged engine provides 32% more output.
- Improved hydraulic performance with 19% more traction force and increased flow and pressure.
- Enhanced maintenance and serviceability with forward-tilting cab design and redesigned counterweight.
SPECIFICATIONS
Model: TB257FR
Class: 5.7 Tonne
Operating Weight: 5725 - 5840 kg
Tipping/Dumping Load Height: 3720 - 3890 mm
Turning Radius: 360
Engine Horse Power: 39.0 kW
Hydraulic Flow Rate: 105 L/min
Ground Pressure: 32.5 - 33.1 kPa
Break-Out Force: 36.6 kN
Machine Dimensions HxWxL: 2620 x 2000 x 3770
